Flexible Fan Coil Unit control options
Covering 2-pipe and 4-pipe applications the TP-710 controllers are available with either BACnet MS/TP or BACnet/IP communications and are supplied with a flexible mix of I/O to cater for 0-10V and 24VAC heat/cool actuator type and 0-10V EC fan control.
Quick & simple commissioning
Built on 20 years of experience
Choice of compatible user interfaces
UK designed, developed and manufactured
Extensive Control Options
All controllers feature an extensive library of control options including:
- Condensate monitoring control
- Fan proving monitoring control
- Electric heating control options
- Fabric protection
- Value exercising and system flush
- Occupancy control options
Simplified Commissioning
AUTO MAC ADDRESSING
No manual addressing required to get your 710 controllers on the network. All TP-C-710 controllers are shipped with our innovative Auto Mac functionality. Controllers automatically address themselves with unique network addresses for visibility into ToolBox where they can then be addressed to the building requirements
SIMPLE INSTALL
The TP-710 controllers have small footprints, LEDs and pluggable terminals to make install easier than ever.
TITAN TOOLBOX
An all new commissioning platform with class leading workflows. Allows complete networks of controllers to be set up in minutes.
ToolBox Commissioning Platform
With the ToolBox platform, commissioning becomes a streamlined process. Controllers are discovered, addressed and commissioned in minutes. ToolBox enables engineers to quickly identify and configure controllers, effortlessly create and copy control profiles and fine-tune control functions. ToolBox places complete control in your hands, ensuring a seamless setup and optimal performance for the TP-710 controllers.
Reliability is a Given
Built on 20 years of FCU control manufacturing experience, the communication stacks & control logic has been tried, tested and enhanced over many product life cycles to deliver robust and reliable controllers that will control buildings for many years.
All TP-710 fan coil controllers are UK Designed, Developed and Manufactured and are fully backed by a 6 year product warranty.
An Interface for Every Application
The new 7” multi-zone touch screens and 4”zonal touch screens are designed to work in conjunction with the TP-710 controllers.
Alternatively, the Rotary Interface provides set point, fan speed adjust and mode adjust along with temperature and humidity sensing with the option for CO2 monitoring, make it the perfect solution for a complete user interface.
| Feature | TP-C-710-IP | TP-C-710 | TP-C-710-IFR |
| BACnet Communications | IP | MS/TP | MS/TP |
| Analogue/Digital Outputs | 3AO 4DO | 3AO 4DO | 3AO 4DO |
| Relay outputs | 2 x NO 1x changeover | 2 x NO 1x changeover | 3 (interlocked) |
| Digital / Analogue inputs | 4 | 4 | 4 |
| Sensor inputs | 3 | 3 | 3 |
| Fan Control | 0-10V | 0-10V | Relay |
| Heat / cool output options | 0-10V 24VAC Raise / Lower 24VAC PWM 24VAC ON/OFF | 0-10V 24VAC Raise / Lower 24VAC PWM 24VAC ON/OFF | 0-10V 24VAC Raise / Lower 24VAC PWM 24VAC ON/OFF |
| Electric heater control options | ✔ | ✔ | ✔ |
| 2 Pipe FCU control | ✔ | ✔ | ✔ |
| 4 Pipe FCU control | ✔ | ✔ | ✔ |
| High/Low limit protection settings | ✔ | ✔ | ✔ |
| Unoccupied options | ✔ | ✔ | ✔ |
